D38999 Connectors

MIL-DTL-38999 connectors, previously known as MIL-C-38999, are available in four primary MIL Type connectors: Series I, II, III, and IV. Series I connectors are used for quick disconnect coupling systems required for blind and difficult mating areas. Series II connectors feature a lower profile to support high vibration and critical environment applications. Series III connectors support high vibration suitable for blinding mating areas with elevated temperatures. Series IV connectors are used for quick disconnect coupling systems required for blind and difficult mating areas.

Shop All MIL-DTL-38999 Connectors

D38999 Overview

D38999 Connectors are the most popular and widely used subminiature circular connectors in the electronic component market for commercial and military applications. D38999 Connectors establish electrical contact and transfer electricity within a device, vehicle, or similar equipment. These connectors are resistant to harsh environments and feature removable crimp or fixed solder contacts, three coupling methods, nine shell sizes, a range of finishes, and a temperature range of -65 to +200 °C.

What industries are D38999 connectors ideal for?

• Industrial
• Commercial
• Mil-Aero

Literature

• A History of MIL-DTL-38999 Connectors
• Amphenol D38999 Catalogs

Supplier Resources

Aero-Electric Connectors

• MIL-DTL-38999 Series I Features and Applications
• MIL-DTL-38999 Series II Features and Applications

Amphenol

• 38999 Plus Connector Catalog and Solutions
• High Density Interconnect Solutions
• MIL-DTL-38999 Catalog for Military, Aerospace, and Harsh Environments

Glenair

• Space-Grade Interconnect Solutions
• SuperNine Mil-Aero Connectors Guide
• High-Speed Interconnect Solutions

ITT Cannon

• 38999-Style Connectors Catalog
• 38999-Style Class G Space Grade Connectors Brochure


Souriau

• Hermetic Sealed Connector Solutions Catalog
• Interconnect Solutions for Space Industry Guide
• Interconnect Solutions for Extreme Environments Guide
