Dynamic Series is a broad product family that provides connector solutions ranging from signal level circuitry through power circuit connectivity in a rugged, industrialized package. The connector family is designed for use in control system applications and is suitable for a wide range of applications requiring high-density, signal and power applications.

Dynamic Series consists of wire-to-board, wire-to-panel and wire-to-wire connectors with diverse housings available to meet most applications. Standard crimp and spring clamp variations of parts are available. The standardized contacts limit the amount of application tooling required.

Dynamic 1000 Series Connectors

• Standard Pitch – 2.0mm
• High-voltage Pitch – 2.5mm
• Spring Clamp Pitch – 3.5mm
• Wire Ranges from 30 AWG to 18 AWG and Handles up to 5A

Dynamic 2000 Series Connectors

• Standard Pitch – 2.5mm
• Wire Ranges from 28 AWG to 18 AWG and Handles up to 5A
• Available in Crimp Version Only

Dynamic 3000 Series Connectors

• Standard Pitch – 3.81mm
• High-voltage Pitch – 5.08mm
• Spring Clamp Pitch – 7.5mm
• Wire Ranges from 28 AWG to 14 AWG and Handles up to 15A

Dynamic 4000 Series Connectors

• Standard Pitch – 6.35mm
• Wire Ranges from 16 AWG to 12 AWG and Handles up to 24A
• Available in Crimp Version Only

Dynamic 5000 Series Connectors

• Standard Pitch – 10.16mm
• Wire Ranges from 20 AWG to 8 AWG and Handles up to 45A
• Available in Crimp Version Only

Dynamic 7000 Series Connectors

• Standard Pitch – 16.0mm
• Wire Ranges from 16 AWG to 6 AWG and Handles up to 65A
• Available in Crimp Version Only
