Phoenix Contact CHARX Protect Surge Protection Devices

Phoenix Contact CHARX Protect Surge Protection Devices are type 3 surge protection, consisting of a protective plug and base element, with integrated status indicator and remote signaling for single-phase power supply networks. These surge protection devices have a nominal voltage of 24V AC/DC and offer a nominal frequency range of 50Hz to 60Hz. Typical applications include data centers, electric vehicle charging stations, industry power supply, transportation systems, and telecommunications.

Features

• Complete protection for charging infrastructure with a comprehensive product range
• Easy to maintain due to consistently pluggable protection modules
• Excellent level of information provided by mechanical/visual status indicator and remote indication contact
• Optimal additional protection of the industrial power supply for longer service life and increased availability of the system
• Protection for the connected e-vehicle with a safe surge protection concept
• Surge protection family for universal use with optimum energy coordination from the lightning current arrester to the device protection
• Uninterrupted continuation of the charging process with a protected power supply
• Preferred connection technology can be selected as both screw connection and Push-in connection

Applications

• Data centers
• Electric vehicle charging stations
• Industry power supply
• Transportation systems
• Telecommunications

Technical Specifications

Product Dimensions
