Panasonic ERJ-P and ERJ-PA Series Sets a New Standard in Resistor Quality

Now you don’t have to choose between quality or other factors when selecting resistors for your design. Panasonic’s cost-effective ERJ Series Resistors deliver high reliability and high performance, with power ratings up to 2W and low ohmic ratings.

The result? Smaller and more efficient electronics built with parts that can handle more power than their predecessors. That’s what we call a higher standard.

Resistors aren’t just one of the most fundamental components in existence –they’re critical to designing lightweight, energy-efficient electronics for just about any application. But with so many parts to choose from, how do you select the right resistors for IoT, industrial technology or wearables without sacrificing performance or affordability? Learn how Panasonic increased power dissipation in Surface-Mount Resistors, increasing maximum power dissipation and pulse current to unlock better performance.

ERJ-PA2 Series – 0.2W

High power resistors in the 0402 case size but which have been engineered to withstand even higher levels of power. This series uses improved trimming and better layouts with Panasonic's soft terminal technology to provide a superior resistor and robust designs.

ERJ-PA3 Series – 0.25W

High-power resistors in the 0603 case size but which have been engineered to withstand even higher levels of power. This series uses improved trimming and better layouts with Panasonic's soft terminal technology to provide a superior resistor. Case size alternative resistors allow more efficient and robust designs.

ERJ-P03 Series – 0.2W

High power resistors in the 0602 case size. This series can handle a higher power rating due to improvements to the trimming pattern and layout of the resistor element.

ERJ-P06 Series – 0.5W

High-power resistors in the 0805 case size. This series can handle a higher power rating due to improvements to the trimming pattern and layout of the resistor element.

ERJ-P08 Series – 0.66W

High-power resistors in the 1206 case size. This series can handle a higher power rating due to improvements to the trimming pattern and layout of the resistor element.

ERJ-P14 Series – 0.5W

Standard thick film chip resistors in the 1210 case size. These parts are made with a traditional printing process that provides a reliable resistor. High power, smaller case size alternative resistors allow more efficient and robust designs.
